+ASM and +APX Instances are not registered with listener.

Listener does not currently know of SID given in connect descriptor.

I’ve moved my blog from https://insanedba.blogspot.com to https://dincosman.com Please update your bookmarks and follow/subscribe at the new address for all the latest updates and content. More up-to-date content of this post may be available there.

After upgrading Oracle grid infrastructure from 11.2.0.4 to 19c; we have detected that +ASM and +APX(ASM Proxy) instances used for advm are not registered with listener and OEM target status shows down.



They were only accessible from the private network (192.168.*.*). We have checked configuration attributes for the ASM instance with the srvctl command.

	* Problematic config
	[oracle@exadb01 ~]$ srvctl config asm
	ASM home: <CRS home>
	Password file: +DATA/orapwASM
	Backup of Password file: +RECO/orapwasm_backup
	ASM listener: ---> This attribute should not be empty.
	ASM instance count: ALL
	Cluster ASM listener: ASMNET1LSNR_ASM
	* How it should be. (Correct one)
	[oracle@s001db01 dbs]$ srvctl config asm
	ASM home: <CRS home>
	Password file: +DATA/orapwasm
	Backup of Password file: +RECO/orapwasm_backup
	ASM listener: LISTENER
	ASM instance count: ALL
	Cluster ASM listener: ASMNET1LSNR_ASM

view raw srvctl_config_asm.txt hosted with ❤ by GitHub

The easy and first step to take was to set it with "srvctl modify" command. Oops something went wrong and that is not possible.

	[oracle@exadb03 ~]$ srvctl modify asm -listener LISTENER
	PRKO-2207 : Warning:-listener option has been deprecated and will be ignored.
	[oracle@exadb01 trace]$ srvctl config asm -proxy -detail
	ASM home: <CRS home>
	ADVM proxy is enabled
	ADVM proxy is individually enabled on nodes:
	ADVM proxy is individually disabled on nodes:
	Spfile:

view raw srvctl_modify_asm_output.txt hosted with ❤ by GitHub

It looks like this command is not working anymore, searched docs.oracle and checked Oracle support but no easy way out. Checked ASM proxy instance local_listener parameter and it was not set. According to the "Real Application Clusters Installation Guide for Linux and UNIX" , If you do not set LOCAL_LISTENER, then the Database Agent process automatically updates the database associated with the local listener in the Grid home, even when the ports or IP address of that listener are changed.

 We found the warnings below in the ASM instance's alert.log.

	...
	01-APR-2022 10:57:20 * (CONNECT_DATA=(CID=(PROGRAM=JDBC Thin Client)(HOST=__jdbc__)(USER=oracle))(SID=+APX1)) * (ADDRESS=(PROTOCOL=tcp)(HOST=XXX.XXX.XXX.XXX)(PORT=40650)) * establish * +APX1 * 12505
	TNS-12505: TNS:listener does not currently know of SID given in connect descriptor
	2022-04-01T10:57:23.208266+03:00
	...

view raw Asm_alertlog_findings6.txt hosted with ❤ by GitHub

Bug 30594507 (Internal) is related to our issue.  According to the bug, start_dependencies are not set for resource group "asmgroup".

In a clean installed and correctly configured cluster, start_dependencies are set as  below.  I have also shown the state for our problematic cluster.

	* Correct one
	[oracle@s001db01 u02]$ crsctl stat resourcegroup ora.asmgroup -p
	NAME=ora.asmgroup
	TYPE=ora.asmgroup.gtype
	...
	START_DEPENDENCIES=weak(global:ora.gns,ora.LISTENER.lsnr) dispersion:active(site:type:ora.asmgroup.gtype)
	START_DEPENDENCIES_RTE_INTERNAL=<xml><Arg name="crslistener" type="ResList">ora.LISTENER.lsnr</Arg></xml>
	START_DEPENDENCIES_TEMPLATE=<xml>weak(global:ora.gns,<ResList>{crslistener}</ResList>) dispersion:active(site:type:ora.asmgroup.gtype)</xml>
	...
	* Problematic one
	[oracle@exadb01 admin]$ crsctl stat resourcegroup ora.asmgroup -p
	NAME=ora.asmgroup
	TYPE=ora.asmgroup.gtype
	...
	START_DEPENDENCIES= --> EMPTY
	START_DEPENDENCIES_RTE_INTERNAL= --> EMPTY
	START_DEPENDENCIES_TEMPLATE=<xml>weak(global:ora.gns,<ResList>{crslistener}</ResList>) dispersion:active(site:type:ora.asmgroup.gtype)</xml>
	...

view raw crsctl_stat_resourcegroup.txt hosted with ❤ by GitHub

We have set start_dependencies for asmgroup with the command below and +ASM and +APX instances used for advm are now registered with listener and OEM target status shows up.

	[oracle@exadb03 ~]$ crsctl modify resourcegroup ora.asmgroup -attr "START_DEPENDENCIES='weak(global:ora.gns,ora.LISTENER.lsnr) dispersion:active(site:type:ora.asmgroup.gtype)'" -unsupported
	[oracle@exadb03 ~]$ crsctl modify resourcegroup ora.asmgroup -attr "START_DEPENDENCIES_RTE_INTERNAL='<xml><Arg name=\"crslistener\" type=\"ResList\">ora.LISTENER.lsnr</Arg></xml>'" -unsupported
	[oracle@exadb03 ~]$ crsctl modify resourcegroup ora.asmgroup -attr "AUTO_START='always'" -unsupported

view raw crsctl_modify_resourcegroup.txt hosted with ❤ by GitHub

Hope it helps.
